The Watec 600CX High-Sensitivity Color Camera is a one-cable image capture system that supports transmission of video and power via a single cable. Moreover, it features EI (electronic iris) control for FL mode.
Watec WAT-600CX Features:
* Service video-out terminal
* Electronic iris control for Flickerless mode
* AGC (Automatic Gain Control)
* Video level switch (100 IRE/75 IRE)
* Screw lens mount
* White Balance Control
* Electronic Shutter
* Flickerless Mode
* Backlight Compensation
* Gamma Correction
* Coaxial (video / power transmission);
* High resolution, high sensitivity;
* White balance control;
* Electronic shutter,
* Electronic iris;
* AGC;
* BLC,
* Gamma correction.
Watec WAT-600CX Specifications:
| Model |
WAT-600CX(NTSC) |
WAT-600CX(PAL) |
| Image Sensor |
1/3" CCD |
| total pixels |
811(H)*508(V) |
795(H)*596(V) |
| Effective Pixels |
768(H)*494(V) |
752(H)*582(V) |
| Pixel Size |
6.35um(H)*7.4um(V) |
6.5um(H)*6.25um(V) |
| imaging system |
Ye, Cy, Mg, and G complementary color mosaic filters on chip |
| Synchronization mode |
internal synchronization |
| Scanning system |
2:1 interlaced scanning |
| video output |
synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance |
| resolution ratio(H) |
More than 540 TVL(Center) |
| minimum illumination |
0.02lx. F1.2(AGC HI) |
| S/N |
More than 50dB(AGC=OFF,¦Ã= 1.0) |
| AE Mode |
Fixed |
1/60 - 1/100(FL) sec. |
1/50 - 1/120(FL) sec. |
| 1/1000sec. |
| EI |
1/60 - 1/100000 sec.(flicker suppress) |
1/50 - 1/100000 sec.(flicker suppress) |
| WB |
ATW(color rolling less), PWB |
| automatic gain control |
ON |
HI:0-38dB / LO:0-32dB |
| OFF |
0dB |
| Gamma Features : |
¦Ã¨P0.45(ON)/¦Ã= 1.0(OFF) |
| lens |
Video /DC(EIAJ arrangement,Auto-select) |
| Image level |
100IRE(ON)/75IRE(OFF) |
| BLC |
ON/OFF |
| Power voltage |
DC + 15V(WAT-400RX) |
| White defect correction |
Up to 32 pixels |
| power consumption |
3.3W(220mA) |
| Maximum cable length |
3C-2V,150m |
| Operating Temperature |
-10 - +50¡æ(Frost-free knot) |
| Storage Temperature |
-30 - +70¡æ(Frost-free knot) |
| Work /Storage humidity |
Lower than 95£¥RH |
| Mount |
CS (Adjustable back focus) |
| Weight |
About 140G |
|
