The SONY SNC-CH210 is a compact and Affordable 1080p HD Security Camera
* Compact and stylish design
* Excellent 1080p HD picture quality, supporting h.264 at 15 fps "Exmor" CMOS sensor
* Three codecs (h.264, MPEG-4, JPEG) and a dual streaming capability
* Stream squared function
* Electrical Day/Night function
Specifications:
|
| Image |
| Image Size |
2048¡Á1536, 1920x1080, 1600x1200, 1680x1056, 1440x912, 1280x1024, 1280x960, 1376x768, 1280x800, 1280x720, 1024x768, 1024x576, 768x576, 720x576, 704x576, 800x480, 720x480, 640x480, 640x368, 384x288 |
| Maximum Frame Rate |
H.264: 15fps (1920¡Á1080) / 30fps (1280¡Á720) MPEG-4: 15fps (1920¡Á1080) / 30fps (1280¡Á720) JPEG: 12fps (2048¡Á1536) / 15fps (1920¡Á1080) / 30fps (1280¡Á720) |
| Camera |
| Minimum Object Distance |
500 mm |
| Electronic Shutter |
1s to 1/10000s |
| Gain |
Auto |
| Exposure Control |
Auto, EV Compensation, Auto Slow Shutter |
| Minimum Illumination |
2.0lx (AGC 38dB / 50IRE[IP]) |
| White Balance Mode |
Auto (ATW, ATW-PRO) , Preset, One-push WB, Manual |
| Image Device |
1/2.8 type progressive scan "Exmor" CMOS sensor |
| F-Number |
F2.8 |
| Horizontal Viewing Angle |
88 degrees |
| Lens Type |
fixed |
| Focal Length |
f=3.3 mm |
| Day/Night function |
Yes (electrical D/N) |
| Horizontal Resolution |
600TVL (Tentative) |
| Compression Format |
H.264, MPEG-4, JPEG |
| Camera Type |
HD Fixed |
| Zoom Ratio |
2.5x (Digital Zoom) |
| Number of Effective Pixels |
3 Megapixel (2096¡Á1561) |
| Analog Video Output |
| S/N Ratio |
more than 50 dB (Tentative) |
| Signal System |
NTSC/PAL |
| Interface |
| Analog Video Output |
Minijack |
| I/O Port |
Sensor in x 1; Alarm out x 0 |
| Network |
10BASE-T/100BASE-TX (RJ-45) |
| General |
| Weight |
100g (3.5 oz) |
| Power Requirements |
PoE (IEEE802.3af compliant) |
| Dimensions (W x H x D) |
44 x 93 mm (1 3/4 x 3 3/4 inches) |
| Power Consumption |
2.4W |
| Operating Temperature |
0¡ãC to 50¡ãC (32¡ãF to 122¡ãF) |
| Storage Temperature |
-20¡ãC to +60¡ãC (-4¡ãF to +140¡ãF) |
| Supplied Accessories |
CD-ROM (User's Guides, and supplied programs), Installation manual, B&P Warranty Booklet, FrontSheet(with logo), FrontSheet(without logo), Sensor input cable |
| Network |
| Protocols |
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP(client only), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) |
| Number of Clients |
5 |
| Authentications |
IEEE802.1X |
| System Requirements |
| Operating System |
Microsoft Windows XP, Windows Vista(32bit), Windows 7(32bit) |
| Processor |
Intel Core2 Duo 2 GHz or higher |
| Memory |
1GB or more |
| Web Browser |
Microsoft Internet Explorer Ver. 6.0, Ver. 7.0, Ver. 8.0, Firefox Ver.3.5 (Plug-in free viewer only), Safari Ver.4.0 (Plug-in free viewer only), Google Chrome Ver.4.0 (Plug-in free viewer only) | |
